11 inch, indoor/outdoor application
Work alone or with pan tilt
Aluminum alloy material
Top open design, easy camera installation
Suitable for short length lens or zoom camera
Optional sunshield, heater, fan, wiper
IP66 ingress protection
Overview
BIT-HS4211 is a 11'' small size security camera enclosure with dual cabin design for multiple devices protection in all-weather situation. Integrated with internal heater, blower fan and wiper, it provides great protection and working environment for network camera. It is a good choice for night vision video surveillance with extra space for IR LED or laser illuminator.
Technical Specifications
Model | BIT-HS4211 | |||
Housing | ||||
Application | Outdoor/Indoor | |||
Dimensions | 315x216x116 mm | |||
Left Cabin Space | 170x70x80 mm | |||
Right Cabin Space | 170x70x80 mm | |||
Window | Ø 58mm (2.28 in) | |||
General | ||||
Power Supply | AC 24V ± 25% | |||
Power Consumption | ≤75W | |||
Working Temperature | -35ºC ~ 60ºC (-31 ºF ~ 140 ºF ) | |||
Working Humidity | ≤90% RH (No condensing, no heating) | |||
Auto Temperature Control | Heating on: 8ºC(46.4ºF ) ±5, off 20ºC(68ºF ) ±5 | |||
Protection Level | IP66 | |||
Material | Alloy aluminum | |||
Weight | 2.5 kg (5.51 lb) | |||
Order Information | Options | |||
Model | Housing Only | Sunshiled | Heater/Fan | Wiper |
BIT-HS4211 | X | / | / | / |
BIT-HS4211K | X | X | / | / |
BIT-HS4211SHK | X | X | X | / |
BIT-HS4211SHKW | X | X | X | X |
Related Products | Model | |||
Pan Tilt | BIT-PT409, BIT-PT410 | |||
Wallmount Bracket | BIT-WS2771, BIT-WS1293, BIT-WS830 | |||
Polemount Bracket | BIT-WS2774/2779 | |||
Dimension:
Unit: mm
